New Product
Si7658ADP
Vishay Siliconix
N-Channel 30-V (D-S) MOSFET
PRODUCT SUMMARY
V DS (V) R DS(on) ( Ω )
0.0022 at V GS = 10 V
30
0.0028 at V GS = 4.5 V
I D (A) a, g
60 g
60 g
Q g (Typ.)
34 nC
FEATURES
? Halogen-free
? TrenchFET ? Gen III Power MOSFET
? 100 % R g Tested
? 100 % Avalanche Tested
RoHS
COMPLIANT
PowerPAK ? SO-8
APPLICATIONS
? Low-Side Switch for DC/DC Converters
- Servers
6.15 mm
1
S
2
S
S
5.15 mm
- POL
- VRM
D
8
D
D
3
4
G
? OR-ing
7
6
D
5
D
G
Bottom View
Ordering Information: Si7658ADP-T1-GE3 (Lead (Pb)-free and Halogen-free)
ABSOLUTE MAXIMUM RATINGS T A = 25 °C, unless otherwise noted
S
N-Channel MOSFET
Parameter
Drain-Source Voltage
Gate-Source Voltage
T C = 25 °C
Symbol
V DS
V GS
Limit
30
± 20
60 g
Unit
V
Continuous Drain Current (T J = 150 °C)
T C = 70 °C
T A = 25 °C
I D
60 g
36 b, c
Pulsed Drain Current
Continuous Source-Drain Diode Current
Single Pulse Avalanche Current
Single Pulse Avalanche Energy
T A = 70 °C
T C = 25 °C
T A = 25 °C
L = 0.1 mH
I DM
I S
I AS
E AS
29 b, c
80
60 g
4.9 b, c
50
125
A
mJ
T C = 25 °C
83
Maximum Power Dissipation
T C = 70 °C
T A = 25 °C
P D
53
5.4 b, c
W
T A = 70 °C
3.4 b, c
Operating Junction and Storage Temperature Range
Soldering Recommendations (Peak Temperature) d, e
T J , T stg
- 55 to 150
260
°C
THERMAL RESISTANCE RATINGS
Parameter
Symbol
Typical
Maximum
Unit
Maximum Junction-to-Ambient b, f
Maximum Junction-to-Case (Drain)
t ≤ 10 s
Steady State
R thJA
R thJC
18
1.0
23
1.5
°C/W
Notes:
a. Based on T C = 25 °C.
b. Surface Mounted on 1" x 1" FR4 board.
c. t = 10 s.
d. See Solder Profile ( http://www.vishay.com/ppg?73257 ). The PowerPAK SO-8 is a leadless package. The end of the lead terminal is exposed
copper (not plated) as a result of the singulation process in manufacturing. A solder fillet at the exposed copper tip cannot be guaranteed and
is not required to ensure adequate bottom side solder interconnection.
e. Rework Conditions: manual soldering with a soldering iron is not recommended for leadless components.
f. Maximum under Steady State conditions is 65 °C/W.
g. Package Limited.
Document Number: 68640
S-81218-Rev. A, 02-Jun-08
www.vishay.com
1
